Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction

Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction

Large Image :  Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction

Product Details:
Place of Origin: Shandong, China
Brand Name: NSR Greenhouse
Model Number: NSR Greenhouse
Payment & Shipping Terms:
Minimum Order Quantity: 100 square meters
Price: $30.00/square meters 100-999 square meters
Contact Now

Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction

Description
Manufacturer: Shandong New Silk Road Greenhouse Instruction For Use: NSR
Size: Large Type: Multi-Span Agricultural Greenhouses
Cover Material: Tempered Glass Suitable Area: Tropical Countries And Sub-tropical Countries
Steel Material: Hot Galvanized Steel Pipe Span Width: 6m/8m/9.6m/10m/12m/Customized
Section: 4 Or 5 M/Customized Gutter Height: 3-5m/Customized
Top Height: 4-7m/Customized Ventilation: Roof Vents/Side Vents
Optional System: Cooling System.irrigation System.ventilation.etc Covering: Temperaed Glass
Keyword: Multi-span Glass Greenhouse

Products Description
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 0
NSR GREENHOUSE - Venlo Type Multi-Span Agricultural Glass Greenhouse
* Venlo-style multi-span glass greenhouse is a kind of sturdy greenhouse. * The surface of the greenhouse is covered with tempered glass, with high light transmittance, strong and beautiful appearance. * The multi-span greenhouse has a high space utilization rate. Ventilation windows can be set on the top and around, with strong ventilation capacity, which can prevent heat loss and cold air intrusion. * Can be used for vegetable and fruit planting, aquaculture, animal husbandry, exhibitions, ecological restaurants, teaching and scientific research, etc.
Product Name
Venlo Type Multi-Span Agricultural Glass Greenhouse
Span
6m/8m/9.6m/10m/12m/Customized
Length
20m/50m/100m/Customized
Shoulder Height
1.5m-1.8m / Customized
Roof Height
3.5m-5.8m / Customized
Wind Load
1.2 kn/㎡
Snow Load
1.0 kn/㎡
Max Rain Quantity
150mm/h
Greenhouse system description
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 1
All steel pipes and connections are hot-dip galvanized
1. Suitable for cold weather areas, such as the United States, Canada, Russia and other regions; 2. The greenhouse has a beautiful appearance and a long service life. It is the highest grade product in the greenhouse; 3. The steel materials used in the greenhouse frame structure and connecting parts are all hot-dip galvanized; 4. The greenhouse frame structure design complies with the Chinese national standard "GB50017-2003 Steel Structure Design Code"; 5. The steel used in the greenhouse complies with the Chinese national standard "GB700-88 Carbon Structural Steel Standard";
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 2

Top cover

1. The top of the greenhouse is usually covered with 4/5mm tempered float glass; 2. The thickness of the glass can also be selected according to the needs of other thicknesses; 3. According to customer needs, choose higher-grade astigmatism glass, which can increase crop yield; 4. According to customer needs, you can choose to cover the top with polycarbonate sheet.
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 3

Wall covering

1. The walls of the greenhouse are usually covered with 4+4/5+5mm tempered hollow float glass; 2. The thickness of the glass can also be selected according to the needs of other thicknesses; 3. According to customer needs, single-layer glass can be selected, which is suitable for parts of the Middle East and Africa; 4. According to customer needs, you can choose to cover the polycarbonate sheet around.
Greenhouse Ventilation System
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 4

Top Ventilation System Of The Greenhouse

1. Ventilation windows can be installed on side 1 or side 2 of the spire on the top of the greenhouse. 2. The opening method of the ventilation window is an electric gear switch. 3. Install anti-insect nets at the vents.
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 5

Side Ventilation System Of The Greenhouse

1. There are vents on both sides of the greenhouse.
2. The opening method of the ventilation window is an electric gear switch, and a sliding window can also be used. 3. Insect nets are installed at the vents.
Greenhouse shading system
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 6

External Shading System

1. The external shading system is fixed on the top of the greenhouse frame, and the shading net is supported by columns and beams.
2. The framework of the sunshade system is the same as that of the greenhouse, using hot-dip galvanized steel pipes.
3. The outer sunshade net is made of black HDPE material and fixed with black polyester rope.
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 7

Internal Shading System

1. The internal shading system is fixed under the circular arch of the greenhouse. 2. The sunshade net of the internal sunshade system is made of aluminum foil + polyester yarn, and the white filter can reflect sunlight and reduce the heat in the greenhouse. 3. The sunshade net has a moisturizing and anti-condensation function, and the woven structure allows sufficient water vapor to pass through and prevents condensation on the lower part of the sunshade net.
Greenhouse heating system
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 8

Heating Boiler

1. According to the area to be heated, different specifications of boilers can be selected. 2. The fuel for the boiler includes natural gas, coal, diesel, biomass, etc.
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 9

Radiator

1. According to the area to be heated, different specifications and quantities of radiators can be selected. 2. The heating methods of the radiator include water heating, electric heating, gas, oil and so on.
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 10

Air Conditioner

1. According to the area to be heated, different specifications and quantities of air conditioners can be selected. 2. It can cool down in summer and heat up in winter.
Greenhouse cooling system
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 11

Cooling Fan

1. The cooling fan is a negative pressure fan, which can exhaust the air in the greenhouse, thereby taking away the heat in the greenhouse. 2. Products of different specifications can be selected according to different greenhouse lengths. Commonly used specifications are 1380*1380mm, 1000*1000mm, etc.
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 12

Cooling Pad

1. The air enters the greenhouse through the Cooling Pad, which plays the role of cooling, humidifying, and air dust removal.
2. The commonly used heights are 1.5 meters and 2 meters, and the thickness is usually 10cm and 15cm.
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 13

Greenhouse Cooling System

1. Through the combination of Cooling fan and Cooling pad, the temperature in the greenhouse can be reduced by more than ten degrees. Combined with the circulation fan and sunshade system, it will have a better cooling effect. 2. In addition, there are high-pressure spray cooling systems and air-conditioning cooling systems.
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 14
Manufacturing Technique
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 15
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 16
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 17
Multi-Span Venlo Greenhouse with Hot Dip Galvanized Steel Frame and NSR Instruction 18
FAQ
Q1: Are you a trading company or a manufacturer? Answer: We are the manufacturer. Our factory produces the main structure of the greenhouse. The equipment of each system in the greenhouse is purchased from the best professional factory in China. We will do our best in every detail. Q2: How to get a quotation for the greenhouse? A: Could you please tell me your specific requirements, such as how much greenhouse area is needed? What will be grown in the greenhouse? Do you need a hydroponic system? We provide the corresponding quotation according to your request. Q3: How should I choose a greenhouse system? A: Please tell us the location of the greenhouse project, we will make our own suggestions based on the local climate, and then we will communicate the details. Q4: Do you provide turnkey projects? What should we do if we do not assemble the greenhouse after purchase? A: We are temporarily unable to provide turnkey projects, only greenhouse materials. But we have professional after-sales service engineers who will provide you with detailed greenhouse drawings. You can communicate with him from time to time. If necessary, we can also send engineers to your country to guide the installation of greenhouses. Q5: Can you provide samples? Is it free or extra? A: We can provide some samples for free, such as steel pipes, coverings, connectors, etc. The equipment in the greenhouse cannot provide free samples. We can mail it to you for free.
