Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost

Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost

Large Image :  Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost

Product Details:
Place of Origin: Shandong, China
Brand Name: NSR Greenhouse
Model Number: NSR Greenhouse
Payment & Shipping Terms:
Minimum Order Quantity: 100 square meters
Price: $10.00/square meters 100-1999 square meters
Contact Now

Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost

Description
Features: Size Can Be Customized Manufacturer: NSR
Instruction For Use: NSR Size: Small
Type: Single-Span Agricultural Greenhouses Cover Material: Plastic Film
Steel Material: Hot Galvanized Steel Pipe Span Width: 6m/8m/9m/10m/12m/Customized
Top Height: 3-5m/Customized Ventilation: Roof Vents/Side Vents
Application: Vegetable And Fruit Planting Covering: 100/120/150/200micro PE Film
Length: 10-100m MOQ: 100 Square Meters
Greenhouse Structure: Double-layer Skeleton And Film

Products Description
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 0
NSR GREENHOUSE - Single Span Double-layer Plastic Film Greenhouse
* The structure of the greenhouse is simple and easy to assemble. It can be fastened by bolts without welding. It is widely used in the cultivation of vegetables and fruits. * The surface of the greenhouse can be covered with a transparent plastic film or two layers. *The steel pipes and connectors used in the greenhouse structure are all hot-dip galvanized, and the service life of the structure is about 20 years. * Ventilation windows can be installed on the top and both sides of the greenhouse, and insect-proof nets can be installed at the vents of the ventilation windows.
Product Name
Single Span Double-layer Plastic Film Greenhouse
Span
5m/6m/7m/8m/9m/10m/12m/Customized
Length
20m/50m/100m/Customized
Shoulder Height
1.5m-1.8m / 2m/Customized
Roof Height
3.5m-5m / Customized
Wind Load
80-130 KM/H
Snow Load
0.5 KN/M2
Max Rain Quantity
140mm/h
Product Advantages
One-Stop Service; MOQ: 1 SET; Can Be Transported Door To Door.
Greenhouse system description
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 1
Greenhouse Frame
1. Single-span double-layer film design, greenhouse size can be customized; 2. According to the climate of the area, you can choose whether to use embedded parts. It can be covered with one or two layers of film, and the outermost layer can also be covered with a quilt. 3. The steel materials used in the greenhouse frame structure and connecting parts are all hot-dip galvanized; 4. The greenhouse frame structure design complies with the Chinese national standard "GB50017-2003 Steel Structure Design Code"; 5. The steel used in the greenhouse complies with the Chinese national standard "GB700-88 Carbon Structural Steel Standard";
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 2
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 3
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 4
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 5
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 6
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 7
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 8
Film type
PE/PO
Film color
Colorless/light blue/custom
Film thickness
0.1mm/0.12mm/0.15mm/0.18mm
/0.2mm/Customized
Service life
3 years/5 years/Customized
Film effect
Anti-ultraviolet, Anti-fog, Anti-aging.
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 9
Insect net type
Insect net
Product specifications:
10-100 mesh/customized;
Service life
3 years/5 years/Customized
width:
1m/1.2m/1.5m/2m-15m (can be spliced)
Material
100% virgin LDPE/LLDPE/EVA/PE with UV treated
Features
Tear resistance,UV resistant,anti-age,dustproof,heat preservation
Greenhouse heating system
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 10

Electric Heaters

1. Output power: 3-45KW; 2580-38700 kcal/h; 2. Output air volume: 210-2400 m³/h;
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 11

Fuel Heater

1. Output power: 20-81KW; 17200-69600 kcal/h; 2. Output air volume: 1550-3300 m³/h; 3. Continuous working time: 17-12 h; 4. Fuel consumption: 1.67-6.8 kg/h; 5. Mailbox capacity: 36-105 L;
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 12

Gas Heater

1. Output power: 18-103KW; 15500-88600 kcal/h; 2. Output air volume: 1000-3260 m³/h;
Greenhouse cooling system
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 13

Cooling Fan

1. The cooling fan is a negative pressure fan, which can exhaust the air in the greenhouse, thereby taking away the heat in the greenhouse. 2. Products of different specifications can be selected according to different greenhouse lengths. Commonly used specifications are 1380*1380mm, 1000*1000mm, etc.
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 14

Cooling Pad

1. The air enters the greenhouse through the Cooling Pad, which plays the role of cooling, humidifying, and air dust removal.
2. The commonly used heights are 1.5 meters and 2 meters, and the thickness is usually 10cm and 15cm.
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 15

Greenhouse Cooling System

1. Through the combination of Cooling fan and Cooling pad, the temperature in the greenhouse can be reduced by more than ten degrees. Combined with the circulation fan and sunshade system, it will have a better cooling effect. 2. In addition, there are high-pressure spray cooling systems and air-conditioning cooling systems.
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 16
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 17
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 18
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 19
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 20
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 21
Economic Large Double Layer Agricultural Greenhouse with Galvanized Steel Frame Poly Tunnel Greenhouse for Plants Low Cost 22
FAQ
Q1: Are you a trading company or a manufacturer? Answer: We are the manufacturer. Our factory produces the main structure of the greenhouse. The equipment of each system in the greenhouse is purchased from the best professional factory in China. We will do our best in every detail. Q2: How to get a quotation for the greenhouse? A: Could you please tell me your specific requirements, such as how much greenhouse area is needed? What will be grown in the greenhouse? Do you need a hydroponic system? We provide the corresponding quotation according to your request. Q3: How should I choose a greenhouse system? A: Please tell us the location of the greenhouse project, we will make our own suggestions based on the local climate, and then we will communicate the details. Q4: Do you provide turnkey projects? What should we do if we do not assemble the greenhouse after purchase? A: We are temporarily unable to provide turnkey projects, only greenhouse materials. But we have professional after-sales service engineers who will provide you with detailed greenhouse drawings. You can communicate with him from time to time. If necessary, we can also send engineers to your country to guide the installation of greenhouses. Q5: Can you provide samples? Is it free or extra? A: We can provide some samples for free, such as steel pipes, coverings, connectors, etc. The equipment in the greenhouse cannot provide free samples. We can mail it to you for free.
