Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m

Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m

Large Image :  Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m

Product Details:
Place of Origin: Shandong, China
Brand Name: NSR GREENHOUSE
Model Number: NSR GREENHOUSE
Payment & Shipping Terms:
Minimum Order Quantity: 500 square meters
Price: $30.00/square meters 500-999 square meters
Packaging Details: LCL use wooden box packaging;<br>The whole box is inserted into the container and loaded into the container to maximize the use of the container.
Supply Ability: 10000 Square Meter/Square Meters per Week Can be coordinated according to the order emergency
Contact Now

Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m

Description
Manufacturer: Shandong New Silk Road Greenhouse Instruction For Use: -
Size: Large Material: PE
Type: Multi-Span Agricultural Greenhouses Cover Material: Film
Layer: Single Span: 6m/8m/9.6m/10m/12m/Customized
Length: 20m/50m/100m/Customized Shoulder Height: 1.5m-1.8m / Customized
Roof Height: 3.5m-5.8m / Customized Wind Load: 0.6 Kn/㎡
Snow Load: 140mm/h Port: QINGDAO

Products Description
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 0
NSR GREENHOUSE-Tunnel type multi-span agricultural film greenhouse
* The tunnel type multi-span film greenhouse is a kind of greenhouse with simple structure. * The surface of the greenhouse is covered with plastic film, which is economical and convenient for installation. * The multi-span greenhouse has good space utilization. Ventilation windows can be set on the top and around it, which has strong ventilation capacity and can prevent heat loss and cold air intrusion. * It can be used for the breeding and planting of vegetables and fruits, aquaculture, animal husbandry, exhibitions, ecological restaurants, teaching and scientific research, etc.
Product Name
Tunnel type multi-span agricultural film greenhouse
Span
6m/8m/9.6m/10m/12m/Customized
Length
20m/50m/100m/Customized
Shoulder Height
1.5m-1.8m / Customized
Roof Height
3.5m-5.8m / Customized
Wind Load
0.6 kn/㎡
Snow Load
0.5 kn/㎡
Max Rain Quantity
140mm/h
Greenhouse system description
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 1

Basic Type

1. Suitable for the growth of plants that do not require high greenhouse height; 2. Suitable for use in areas where the wind is not strong; 3. The frame structure of the greenhouse and the steel used in the connecting parts are all hot-dip galvanized; 4. The frame structure design of the greenhouse complies with the Chinese national standard "GB50017-2003 Steel Structure Design Code"; 5. The steel used in the greenhouse complies with the Chinese national standard "GB700-88 Carbon Structural Steel Standard";
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 2

Enhanced Type

1. Suitable for the growth of plants with high requirements for greenhouse height; 2. Suitable for use in areas with strong wind; 3. The frame structure of the greenhouse and the steel used in the connecting parts are all hot-dip galvanized; 4. The frame structure design of the greenhouse complies with the Chinese national standard "GB50017-2003 Steel Structure Design Code"; 5. The steel used in the greenhouse complies with the Chinese national standard "GB700-88 Carbon Structural Steel Standard";
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 3
Film type
PE/PO
Film color
Colorless/light blue/custom
Film thickness
0.1mm/0.12mm/0.15mm/0.18mm
/0.2mm/Customized
Service life
3 years/5 years/Customized
Film effect
Anti-ultraviolet, Anti-fog, Anti-aging.
Greenhouse Ventilation System
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 4

Top Ventilation System Of The Greenhouse

1. There are vents on both sides of each round arch at the top of the greenhouse. 2. The vent opening method is electric roll film switch. 3. Insect nets are installed in the vents.
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 5

Side Ventilation System Of The Greenhouse

1. There are vents on both sides of the greenhouse. 2. The vent opening method is electric roll film switch. 3. Insect nets are installed in the vents.
Greenhouse shading system
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 6

External Shading System

1. The external shading system is fixed on the top of the greenhouse frame, and the shading net is supported by columns and beams.
2. The framework of the sunshade system is the same as that of the greenhouse, using hot-dip galvanized steel pipes.
3. The outer sunshade net is made of black HDPE material and fixed with black polyester rope.
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 7

Internal Shading System

1. The internal shading system is fixed under the circular arch of the greenhouse. 2. The sunshade net of the internal sunshade system is made of aluminum foil + polyester yarn, and the white filter can reflect sunlight and reduce the heat in the greenhouse. 3. The sunshade net has a moisturizing and anti-condensation function, and the woven structure allows sufficient water vapor to pass through and prevents condensation on the lower part of the sunshade net.
Greenhouse heating system
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 8

Heating Boiler

1. According to the area to be heated, different specifications of boilers can be selected. 2. The fuel for the boiler includes natural gas, coal, diesel, biomass, etc.
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 9

Radiator

1. According to the area to be heated, different specifications and quantities of radiators can be selected. 2. The heating methods of the radiator include water heating, electric heating, gas, oil and so on.
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 10

Air Conditioner

1. According to the area to be heated, different specifications and quantities of air conditioners can be selected. 2. It can cool down in summer and heat up in winter.
Greenhouse cooling system
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 11

Cooling Fan

1. The cooling fan is a negative pressure fan, which can exhaust the air in the greenhouse, thereby taking away the heat in the greenhouse. 2. Products of different specifications can be selected according to different greenhouse lengths. Commonly used specifications are 1380*1380mm, 1000*1000mm, etc.
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 12

Cooling Pad

1. The air enters the greenhouse through the Cooling Pad, which plays the role of cooling, humidifying, and air dust removal.
2. The commonly used heights are 1.5 meters and 2 meters, and the thickness is usually 10cm and 15cm.
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 13

Greenhouse Cooling System

1. Through the combination of Cooling fan and Cooling pad, the temperature in the greenhouse can be reduced by more than ten degrees. Combined with the circulation fan and sunshade system, it will have a better cooling effect. 2. In addition, there are high-pressure spray cooling systems and air-conditioning cooling systems.
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 14
Manufacturing Technique
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 15
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 16
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 17
Affordable NSR Greenhouse Tunnel for Strawberry Cultivation Roof Height 3.5m-5.8m 18
FAQ
Q1: Are you a trading company or a manufacturer? Answer: We are the manufacturer. Our factory produces the main structure of the greenhouse. The equipment of each system in the greenhouse is purchased from the best professional factory in China. We will do our best in every detail. Q2: How to get a quotation for the greenhouse? A: Could you please tell me your specific requirements, such as how much greenhouse area is needed? What will be grown in the greenhouse? Do you need a hydroponic system? We provide the corresponding quotation according to your request. Q3: How should I choose a greenhouse system? A: Please tell us the location of the greenhouse project, we will make our own suggestions based on the local climate, and then we will communicate the details. Q4: Do you provide turnkey projects? What should we do if we do not assemble the greenhouse after purchase? A: We are temporarily unable to provide turnkey projects, only greenhouse materials. But we have professional after-sales service engineers who will provide you with detailed greenhouse drawings. You can communicate with him from time to time. If necessary, we can also send engineers to your country to guide the installation of greenhouses. Q5: Can you provide samples? Is it free or extra? A: We can provide some samples for free, such as steel pipes, coverings, connectors, etc. The equipment in the greenhouse cannot provide free samples. We can mail it to you for free.
